Chapter 3 BIOS Setup
21
Chapter 3
Main
The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day, from Sun-
day to Saturday. Month displays the month, from January to December. Date displays
the date, from 1 to 31. Year displays the year, from 1980 to 2099.
System Time
The time format is <hour>, <minute>, <second>. The time is based on the 24-hour
military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to
23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.
Set the Date. Use TAB
to switch between Data
elements.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Save & Exit
Chipset
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
BIOS Information
BIOS Vendor
Core Version
Project Version
Build Date
Memory Information
MRC Version
Total Memory
System Date
System Time
Access Level
American Megatrends
4.6.3.7
OABTN 0.32
12/18/2012 14:19:08
01.00
1024 MB (DDR2)
[Thu
01
/01/2009]
[18:36:56]
Administraor
Advanced
Boot
Security
Main
AMI BIOS Setup Utility
Enable or Disable Boot
Option for Legacy Net-
work Devices.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Legacy OpROM Support
Launch PXE OpROM [Disabled]
Launch Storage OpROM [Enabled]
APCI Settings
CPU Confi guration
SDIO Confi guration
USB Confi guration
Module Board H/W Monitor
Save & Exit
Chipset
Boot
Security
Main
Advanced
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
Launch Storage OpROM
Enable or Disable Boot Option for Legacy Mass Storage Devices with Option ROM.
Advanced
The Advanced menu allows you to configure your system for basic operation. Some entries are
defaults required by the system board, while others, if enabled, will improve the performance
of your system or let you set some features according to your preference.
Important:
Setting incorrect field values may cause the system to malfunction.
