Chapter 3 BIOS Setup
Chapter 3
Main
The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day, from Sun-
day to Saturday. Month displays the month, from January to December. Date displays
the date, from 1 to 31. Year displays the year, from 1980 to 2099.
System Time
The time format is <hour>, <minute>, <second>. The time is based on the 24-hour
military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to
23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.
AMI BIOS Setup Utility
Advanced
The Advanced menu allows you to configure your system for basic operation. Some entries are
defaults required by the system board, while others, if enabled, will improve the performance
of your system or let you set some features according to your preference.
Set the date. Use Tab
to switch between date
elements
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Save & Exit
Chipset
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
BIOS Information
BIOS Vendor
Core Version
Compliency
Project Version
Model Name
Bios Name
Bios Version
Build Date and Time
System Date
System Time
Access Level
American Megatrends
4.6.5.1
UEFI 2.3; PI 1.2
1APJK 0.15.013 x64
DFI-CD951
CD9510C5.28A
RA07
05/28/2012 23:08:56
[Mon
05
/28/2012]
[10:44:27]
Administraor
Advanced
Boot
Security
Main
F81866A WDT Parameters.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Legacy OpROM Support
Launch PCI-E NIC PXE [Disabled]
Launch I82574 WOL [Disabled]
Launch Resume on Ring [Disabled]
Launch Storage OpROM [Enabled]
PCI Subsystem Settings
ACPI Power Management Confi guration
CPU Confi guration
IDE Confi guration
USB Confi guration
Super IO Confi guration
PC Health Status
JMB36X ATA Ctrl Confi g
PPM Confi guration
WatchDog Confi guration
Save & Exit
Chipset
Boot
Security
Main
Advanced
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
Legacy PCI-E NIC PXE
Enable or Disable Boot option for Realtek 8111DL NIC.
Launch I82574 WOL
Enable or Disable WOL for Intel 82574 LAN Option.
Launch Resume on Ring
Enable or Disable resume on ring option.
Launch Storage OpROM
Enable or Disable Boot Option for Legancy Mass Storage Devices with Option ROM.
Important:
Setting incorrect field values may cause the system to malfunction.
