A S S E M B LY
I N S T R U C T I O N S
F R A M E A S S E M B L Y
Step 2c
FITNESS SYSTEMS
R
HOIST
In this step start by pressing two of the (21) into (5). Take two of the
(20) and place them over the two holes in the bottom of (5). Now slide
two of the (17) into the holes. Make sure to lube (17) with Spindle Oil.
Next slide 15 of the (19)and one (18) onto (19). Make sure (19) and (17)
are sitting level. Next, secure (2) to(18) then attach two of the (23) to (2)
and (5). Slide on three of the (24) on either (2) or (5). Then
bolts including all previously hand tightened bolts.
Wrench
tighten
2 - Center RH BRK (Add-On)
5 - Weight Cage Assy.
17 - Guide Rod
18 - 8.6 lbs. Top Plate
19 - 20 lbs. Intermediate Weight
20 - Weight Bumper
21 - Guide Rod Bushing
22 - Weight Selector Pin
23 - Add On Weight
24 - 5 lbs. Add On Weight
39 - Add On Weight Bushing
Part Descriptions
C - 3/8-16 x 2 3/4” Button Head Screw
D - 5/16-18 x 1” Button Head Screw
E - 3/8-16 x 1” Button Head Screw
F - 3/8-16 x 1” Button Head Screw
AB - 3/8” Split Washer
AC - 3/8” Internal Lock Washer
AD - 3/8” Internal Lock Washer
AE - 5/16” Internal Lock Washer
AH - 3/8” Flat Washer
AJ - 3/8” Flat Washer
AK - 5/16” Flat Washer
CA - Selector Pin Lanyard
CE - Guide Bearing
CF - Guide Bearing
Hardware Descriptions
2412 Assembly
