A S S E M B LY
I N S T R U C T I O N S
F R A M E A S S E M B L Y
Step 2b
FITNESS SYSTEMS
R
HOIST
Attach (37) to (5). bolts.
Wrench tighten
5 - Weight Cage Assy.
37 - Shield
Part Descriptions
A - 1/2-13 x 1 ½” Button Head Screw
AA - 1/2” Internal Lock Washer
AG - 1/2” Flat Washer
CB - 1/2” Insert
Hardware Descriptions
2412 Assembly
Page 21
