Hoist – Hoist Fitness CL-2412 User Manual
Page 25
A S S E M B LY
I N S T R U C T I O N S
FITNESS SYSTEMS
R
HOIST
2412 Assembly
Page 24
H A R D W A R E L I S T I N G
Key #
Qty.
Part Number
Description
A
12
11-BTN-12112WZ
1/2-13 x 1 1/2" Button Head Screw
B
8
11-BTN-38114
3/8-16 x 1 1/4" Button Head Screw
C
2
11-BTN-38234WZ
3/8-16 x 2 3/4" Button Head Screw
D
2
11-BTN-5161
5/16-18 x 1" Button Head Screw
E
1
11-BTN-381
3/8-16 x 1" Button Head Screw
F
1
11-BTN-381WZ
3/8-16 x 1" Button Head Screw
G
6
11-BTN-38134WZ
3/8-16 x 1 3/4" Button Head Screw
H
4
11-HEX-516334WZ
5/16-18 x 3 3/4" Hex Head Bolt
J
4
11-BTN-516114WZ
5/16-18 x 1 1/4" Button Head Screw
K
2
11-FLA-381WZ
3/8-16 x 1" Flat Head Cap Screw
L
8
11-SET-10(32)18
#10-32 Set Screw
M
4
11-SKT-14112
1/4-20 x 1 1/2" Socket Head Screw
N
1
11-SET-3834SQFD
Square Head Set Screw
P
2
11-BTN-141
1/4-20 x 1" Button Head
AA
12
13-LOK-12INT
1/2" Internal Lock Washer
AB
2
13-LOK-38WZ
3/8" Split Washer
AC
9
13-LOK-38INTB
3/8" Internal Lock Washer
AD
7
13-LOK-38INT
3/8" Internal Lock Washer
AE
2
13-LOK-516INTB
5/16" Internal Lock Washer
AF
8
13-LOK-516INT
5/16" Internal Lock Washer
AG
12
13-FLT-12SAEWZ
1/2" Flat Washer
AH
9
13-FLT-38SAE
3/8" Flat Washer
AJ
9
13-FLT-38SAEWZ
3/8" Flat Washer
AK
2
13-FLT-516SAE
5/16" Flat Washer
AL
8
13-FLT-516SAEWZ
5/16" Flat Washer
AM
6
13-LOK-14INTB
1/4" Flat Washer
AN
4
13-FLT-14SAE
1/4" Flat Washer
BA
8
12-LOK-38TWZ
3/8" Lock Nut (Thin)
BB
1
12-FLG-12(13)SB
Serrated Hex Nut
CA
1
10-LRD-12
Selector Pin Lanyard
CB
10
1/2-13UNC
Insert
CC
1
19-PAD-1
Plug Bumper
CD
1
30-RPN-7163
7/16" x 3" Open Roll Pin
CE
1
14-BRG-PAC4962
Guide Bearing
CF
1
14-BRG-PAC4982
Guide Bearing
CG
2
18-PUL-325\W38T
3 1/4" Pulley
CJ
1
14-RNG-ERETRG(1/4)
C-Clip
CK
1
15-BLT-1516
Cam Belt 1/8" x 15/16" x 75"
CL
1
16-CAP-22
2" x 2" End Cap
CM
2
14-BRG-4B1
Bearing
CN
1
30-RPN-382S
3/8" x 2" Spiral Roll Pin
