A S S E M B LY
I N S T R U C T I O N S
F R A M E A S S E M B L Y
Step 2b
FITNESS SYSTEMS
R
HOIST
In this step start by attaching (CM) to (5) and make sure to put zerk
fitting facing down, then attach (9) to (5). Next, slide (16) through one
(CM) then through (9) and through another (CM). Then secure (16) and
(9) with (CN). After (9) is secure to (5) attach (K) to both ends of (16).
bolts only, they will be tightened later.
Hand Tighten
5 - Weight Cage Assy.
9 - Pivoting Foot Plate Assy.
15 - Aluminum Cap
16 - Shaft
Part Descriptions
B - 3/8-16 x 1 1/4” Button Head Screw
K - 3/8-16 x 1” Flat Head Cap Screw
AC - 3/8” Internal Lock Washer
AH - 3/8” Flat Washer
AJ - 3/8” Flat Washer
BA - 3/8” Lock Nut
CC - Plug Bumper
CM - Flange Bearing
CN - 3/8” x 2” Spiral Roll Pin
Hardware Descriptions
2412 Assembly
Page 7
