A S S E M B LY
I N S T R U C T I O N S
F R A M E A S S E M B L Y
Step 2d
FITNESS SYSTEMS
R
HOIST
Slide (25) up into (18) and secure with (CD). bolts.
Wrench tighten
18 - 8.6 lbs. Top Plate
25 - Stem (16) Holes
Part Descriptions
CD - 7/16” x 3” Open Roll Pin
Hardware Descriptions
2412 Assembly
Page 11
