10
Gas flow adjustment
In order to adjust the minimum gas flow proceed as
follows:
• Ignite the burner and turn down to the minimum
setting.
• Remove the control knob from the gas tap.
•
Adjust the flow either clockwise to decrease
or anti-clockwise to increase the flame. Use a
screwdriver inserted down the gas tap rod or via
the screw head adjacent to the rod for models
fitted with a Flame Supervision Device.
• Check that the flame is 3- 4 mm in length, bluish
in colour, stable and noiseless, and does not
extinguish when changing from maximum to
minimum flow.
• Replace the control knob and check that all
components have been reassembled ·correctly.
Before leaving – Check all connections for gas leaks
with soap and water. DO NOT use a naked flame for
detecting leaks. Ignite all burners to ensure correct
operation of gas valves, burners and ignition. Turn
gas taps to low flame position and observe stability
of the flame. When satisfied with the hotplate, please
instruct the user on the correct method of operation.
In case the appliance fails to operate correctly after all
checks have been carried out, refer to the authorised
service provider in your area.
adaptation to various
types of gas (Fig. 7)
Should the appliance be pre-set for a different type
of gas than available, proceed as follows:
Replace the injector (fig. 7) with the corresponding type
of gas to be used (see table “User characteristics“);
Adjust to the minimum, use a screwdriver on the
screw placed on the tap (Fig. 8) after turning the tap
to its minimum position.
For LPG (propane) screw tight.
Figure 7
Figure 8
Figure 9
