11
User characteristics
electrical connection
Before connecting the appliance, make sure
the supply voltage marked on the rating Plate
corresponds with the mains supply voltage.
WARNING – THIS APPLIANCE MUST BE EARTHED
Ensure the appliance is plugged into a 1O amp GPO
IMPORTANT
The wires in the main supply lead are coloured
in accordance with the following code:-
Green and Yellow Earth
Blue Neutral
Brown Live
The connections must be made as follows:-
• The wire coloured Green and Yellow must be
connected: to the terminal marked ‘E’ or the earth
symbol or coloured green and yellow.
• The wire coloured Blue must be connected to the
terminal marked ‘N’ or coloured blue or Black.
• The wire coloured Brown must be connected to
the terminal marked ‘L’ or coloured brown or red.
NOTE: The terminals marked ‘SUPPLY’ are for the mains supply wires
and the terminations marked ‘LOAD’ are for the appliance wires.
The electrical outlet is to be positioned in an easily
accessible position adjacent to the appliance.
In the event that it is necessary to replace the mains
supply lead, the replacement must conform to the
specification listed in the Technical Data. Ensure that
the colour code connection is correct and that all
screws are tightened correctly.
rigid/semi rigid metal connection
Carry out the connection with fittings and metal
pipes (even flexible pipes) so as to obtain counter
stress the inner parts of the appliance.
N.B. – when the installation has been carried out, check the
perfect sealing of the entire connection system, by using a soapy
solution.
Prior to carrying out the electrical connection, please
ensure that:
• the plant characteristics are such as to follow
what is indicated on the matrix plate placed at the
bottom of the working area;
• That the plant is fitted with an efficient earth
connection, following the standards and law
provisions in force. The earth connection is
compulsory in terms of the law.
