13
maintenance
WARNING: SERVICING SHOULD BE CARRIED
OUT ONLY BY AUTHORISED PERSONNEL
During the warranty period, in case of need all
service intervention should be referred back to the
Kleenmaid Service Department. Please note that
intervention or repair by any unauthorised personnel
will invalidate such warranty.
Before carrying out any maintenance, disconnect
the appliance from the gas and electricity supplies.
If a gas tap becomes stiff to operate, proceed as
follows:
• Remove the control knobs, pan supports, burners
and cooktop fixing screws & clamps.
• Remove the Cooktop from the worktop and
remove any underside protective covers.
• Disconnect the fixings holding the tap to the fascia
panel, separate the assembly, then clean the cone
and seating with a cloth dampened with solvent.
• Lightly smear the cone with high temperature
grease, reassemble into position and rotate a few
times. Remove the cone again and remove any
excess grease making sure that the gas ducts are
not obstructed with grease.
• Carefully reassemble the components and check
for gas soundness.
• If it becomes necessary to replace the gas tap,
proceed as follows:
• Disconnect the appliance as described above.
•
Disconnect the gas pipe from the gas tap,
disassemble from the gas rail by removing the
fixing screws.
• When fitting a new tap, ensure that a new gasket
is used.
• Re-connect the gas tap, check for gas soundness
and reassemble the cooktop.
technical data
electrical details
Rated Voltage 230V ac 50Hz
Supply Connection 1OAmp GPO
Power Input 0.008 to 0.02kW (depending on model)
Mains supply lead 3 x 0.75mm
2 Type RR-F <HAR>
marked
A recommended maintenance schedule is
suggested to ensure your product is in optimal
working condition.
Gas details
Connection Type
1/2” BSP
Natural Gas 1.00 kPa – ALTERNATIVE LPG 2.75 kPa
