9
Gas connection
Data Label – The Data Label is located on the
underside of the appliance. A duplicate label is
supplied to adhere in an accessible area adjacent to
the appliance. This appliance is suitable for Natural
Gas and propane Gas; ensure that the available gas
supply matches the Data Label
The appliance is factory set for Natural gas but
can be converted to LPG (Propane). The test point
pressure should be adjusted to 1.00 kPa for Natural
Gas and 2.75 kPa for Propane, with the relevant
burners operating at maximum as in the table above.
Connect the appliance to the gas cylinder or to the
installation according to the prescribed standards
in force, and ensure beforehand, that the appliance
matches the type of gas available. Otherwise, see
”Adaptation to various types of gas”. Furthermore,
check that the feed pressure falls within the values
described on the table. ”User characteristics ”.
When converting from Natural Gas to Propane ensure
that the NG regulator is removed and replaced with
the Test Point Assembly. A gas regulator suitable
for a supply pressure of 2.75 kPa should be part of
the gas tank supply. Replace the old data plate with
one, which is suitable for the type of gas for which
the appliance has been regulated.
The gas supply must be connected by use of the
1/2” BSP Elbow, Seal and copper pipe and an
isolation tap fitted in an easily accessible position.
Model T.P.P. (kPa) Burners
natural Gas propane (LpG)
GCT6010 1 2.75 Wok+ Rapid
GCT9010 1 2.75 Wok+ Rapid
Figure 5
