• The team and loopback are named
1. If not already open, open Network Connections as follows:
a) From the Windows taskbar, click Start | Network .
The Network window opens.
b) Click Network and Sharing Center .
Network and Sharing Center opens.
c) Click Change Adapter Settings .
Network Connections opens.
2. Select Advanced , then Advanced Settings…
3. On the Adapters and Bindings tab, order adapters as follows:
• On systems with no 10 Gig network interface card installed, the specified order is as follows
Control Connection
FTP-Streaming Connection
Unused Connection 1
Unused Connection 2
• On systems with a 10 Gig network interface card installed, the specified order is as follows
Control Connection
FTP 10G Connection
Unused Connection 1
Unused Connection 2
Unused Connection 3 10G
4. Click OK to close and accept the changes.
5. Close Network Connections.
If continuing with network configuration, next set power management settings.
Set power management settings
1. If not already open, open Network Connections as follows:
a) From the Windows taskbar, click Start | Network .
The Network window opens.
b) Click Network and Sharing Center .
Network and Sharing Center opens.
c) Click Change Adapter Settings .
Network Connections opens.
292 K2 SAN Installation and Service Manual 02 February 2012
Administering and maintaining the K2 SAN
