Overview of cables and adapters
57
Figure E
Measurement at the 25-pin speed encoder input of the TNC (control side):
EnDat absolute encoders with sinusoidal A/B signals and ordering designation EnDat 01 and
EnDat 02
Synchronous motors EnDat / SSI
