Silvercrest SFW 350 C1 - Manual (Page 10)

7
GB
SFW 350 C1
Assembling the kubbe attachment
Unfold the fold-out side. There you will fi nd the step-by-step illustrations for as-
sembling the appliance.
1) Remove the meat grinder casing 5 as described under “Assembling the
meat grinder”.
2) Disassemble any attachments that might be fi tted and clean the meat grinder
casing 5.
NOTICE
► For the kubbe attachment e, the cross blade 8 with the spring 7 is not
required! If need be, remove them both from the meat grinder casing 5.
3) Coat all metal parts with cooking oil.
4) Insert the two plastic parts of the kubbe attachment e so that the fi xings on
the bottom kubbe attachment e ring are located in the openings in the meat
grinder casing 5.
5) When everything has been attached correctly, screw the ring clamp 0 back
on hand-tight.
6) Assemble the meat grinder casing 5 as described under “Assembling the
meat grinder”.
Assembling the biscuit attachments
Unfold the fold-out side. There you will fi nd the step-by-step illustrations for as-
sembling the appliance.
1) Remove the meat grinder casing 5 as described under “Assembling the
meat grinder”.
2) Disassemble any attachments that might be fi tted and clean the meat grinder
casing 5.
NOTICE
► For the biscuit attachment 1, the cross blade 8 with the spring 7 is not
required! If need be, remove them both from the meat grinder casing 5.
3) Coat all metal parts with cooking oil.
4) Pull the pattern strips 1 away from the front of the biscuit attachment 1.
5) First place the plastic disc and then the metal disc of the biscuit attachment 1
into the meat grinder casing 5 (see fold-out side). Insert the biscuit attach-
ment 1. so that the fi xings on the biscuit attachment 1. are located in the
openings in the meat grinder casing 5.
6) After everything has been correctly assembled, screw the ring clamp 0
back on hand-tight.
