Modero G5 Touch Panels - Installation & Hardware Reference Manual 20 | TOC
MD-702 Specifications (Cont.)
Touch Screen Display • Display Type: TFT Active Matrix Color LCD with Fringe Field Switching (FFS) - Wide viewing angle
• technology
• Display Size (WH): Landscape: 7.3” x 4.8” (186mm x 122mm), 8.8” (222mm) diagonal
• Viewable Area (WH): Landscape: 6.05” x 3.54” (154mm x 90mm), 7.0” (178mm) diagonal
• Resolution: Landscape: 1024x600
• Aspect Ratio: Landscape: 16:9
• Brightness: 400 cd/m2
• Contrast Ratio: 800:1
• Color Depth: 16.7M colors
• Illumination: LED
• Touch Overlay: Projected capacitive, multi-touch support, 3 simultaneous max
Note: Touch Panel Aspect Ratio: While the touch panel screen physical dimensions fall between 16:9
and 16:10, any incoming video stream can be scaled to 16:9 if needed. This may lead to some letter
boxing around the video in some cases.
Viewing Angle 89°/89°/89°/89° (Up/Down/Left/Right)
Memory • SDRAM: 2 GB
• Flash: 16 GB
• Maximum Project Size: 12 GB flash, available for apps and touch panel files
Communications • Ethernet: 10/100 Auto MDI-X port, RJ-45 connector. Supported IP and IP-Based Protocols: UCP,
TCP, ICMP, ICSP, IGMP, DHCP, SSH, FTP, DNS, RFB (for VNC), HTTP
• USB: (2) USB host 2.0, Type A ports (1 with limited physical access requiring right angle
connection): Firmware upgrade, Touch Panel File Transfer, document and image viewing, HID
Peripherals
• Bluetooth*:
Mouse/Keyboard: HID Profile v1.1
Handset: Hands Free Profile v1.5, Headset Profile v1.2
Video • Supported Video Codecs:
MPEG2-TS: MPEG-2 Main Profile@High Level up to 720p at 25 fps (decode only)
MPEG-2-TS: H.264 High Profile@Layer 4, AAC-LC up to 720p at 25 fps (decode)
MJPEG up to 720p at 25 fps (decode only)
• Supported Video Transport Streams: MPEG-TS for MPEG2 and H.264; HTTP for MJPEG
• Max Number of Active Video Streams: 2 (720dpi/30fps)
Audio • Microphone: -42 dB ±3 dB sensitivity FET microphone
• Speakers: 4 ohm, 2 Watt, 300 Hz cutoff frequency
• Supported Audio Codecs: MP2 Layer I and II, MP3 (8 kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz,
24 kHz, 32 kHz, 44.1 kHz, 48 kHz), AAC-LC (8 kHz, 96 kHz), G.711 with μLaw (VoIP* encode/decode
at 8 kHz)
Suggested max packet size for G.711 Voice: 20ms
• File Formats: WAV, MP3 (as part of touch panel file only - no USB storage)
• Intercom*: Full Duplex VoIP, SIP v2.0
Graphics Engine AMX G5: G5 enhanced feature set supporting multi-touch and gestures, scrolling, transitions,
applications - See TPD5 Operations Guide for more information
Embedded
Applications
• Viewer Applications: PDF, JPEG, BMP, PNG, TIFF, GIF
• Remote Management: VNC Server
• The MXD-701 receives audio/video and returns audio
• Audio Conferencing: Audio (Full Duplex Intercom*)
Front Panel
Components
• Sleep Button: Sleep button to activate sleep mode and powering off. Also provides access to setup
pages (can be disabled)
• Programmable Red/Green LEDs: Programmable red/green LED in the front, left and right sides of the
panel, LEDs are beautifully recessed and nearly invisible when not lit
Connections • Ethernet: 10/100 port, RJ-45 connector
• USB: (1) USB host 2.0, type A port
• Power: PoE (Power over Ethernet), 802.3at, class 0
Environmental • Temperature (Operating): 32°F to 104°F (0°C to 40°C)
• Temperature (Storage): 4°F to 140°F (-20°C to 60°C)
• Humidity (Operating): 20% to 85% RH
• Humidity (Storage): 5% to 85% RH
• Power (“Heat”) Dissipation:
On: 49.5 BTU/hr
Standby: 19.8 BTU/hr
Included Accessories • Installation Template 7” (68-2265-02)
• Backbox, Wall Mount, 7” (5095917-00)
* This feature will be available upon release of a future firmware update.
