54
Wireless Settings
During radio transmission wireless shooting, the master unit’s LCD
panel illuminates or turns off according to the charge status of the
master unit and slave units (firing groups). The master unit’s LCD panel
illuminates if the master unit and slave units are not fully charged. When
the master unit and slave units are fully charged, the LCD panel
illumination will turn off after approx. 12 sec. As the charge for the
master unit and slave units becomes insufficient when you take a
picture, the master unit’s LCD panel will be illuminated again.
You can save the wireless settings to the master unit and slave unit,
and recall the settings later. Operate the master unit or slave unit
separately depending on which unit’s settings are to be saved or
recalled.
1
Select < L >.
Press the < 1 > button.
Turn < 9 > to select < L >, then
press < 8 >.
2
Save or load the settings.
Turn < 9 > to select < V > (save)
or < J > (load), then press < 8 >.
Select < ; >.
X The settings are saved (stored in the
memory) or the settings that were
saved are set.
LCD Panel Illumination
Memory Function
If any of the master unit or slave unit (firing group) is not fully charged,
<
G > will be displayed on the master unit’s LCD panel. Make sure to
take the picture after checking either the < G > icon is not displayed on
the LCD panel or the LCD panel is not illuminated.
