- 7 -
Video 60 Plus EFP Manual
Б Б
having heard the balance plate snapping in you
carefully open the tilt safety lock
Б Б
fine adjustment can now be performed via the
spindle drive
Б Б
last but not least you apply the lock of the balance
plate again
3.7 Setting of the Damping
The Video 60 Plus EFP is equipped with nine damping
levels horizontally and vertically and a zero setting. By tur-
ning the vertical setting and the horizontal setting one sel-
ects the desired level of the fluid damping.
Turn the setting ring to ”0” in order to switch off the dam-
ping completely.
If you set the setting rings on the same index number
(e. g. ”3”) the degree of the horizontal and vertical dam-
ping is identical and thus enables precise diagonal pan-
ning movements without jerks and vibrations.
3.8 Brakes
The horizontal brake applies the lock for the pan and the
vertical brake for the tilt movement. Both brakes are
vibrationless and can be used during shooting.
3.9 Support for view finder extension
The Video 60 Plus EFP has on its left side a preparation to
accept a support system for a view finder extension.
3.10 Change of the batteries
The illumination is powered by three standard type button
cells (625 U or LR9) located in the battery holder, which
can be opened with a sharp object such as a screwdriver.
Make sure to insert the new batteries according to the
”plus” and ”minus” symbols as indicated in the covering
plate.
The batteries last for about 2000 illumination cycles.
