Video 60 Plus EFP Manual
Guide the balance plate with spindle into the base
plate.Turn the spindle to the right until you can see it
coming out at the front of the head.
Place the fixation screw in the spindles top end and tigh-
ten it. The spindle is now fastened. The conversion is
done.
5.2 Conversion of pan bars and rosette
Open the 4 screws of the pan bar rosette and remove it.
If this is not possible hammer the positioning pins through
to the inside.
Replace the rosette against another one from the Sachtler
accessory range and position it first with the two
pins.Place the 4 allen screws and fasten them hand-
tight.Now you can use other pan bars.
5.3 Conversion of Video 60 Plus EFP to include flat base
Put the Video 60 Plus EFP upside down, so that you can
access the bottom of the head.Next to the centre bolt you
will see 4 allen screws. Those have to be unscrewed and
the whole piece has to be removed.
Now the Video 60 Plus EFP can be mounted onto flat
base tripods and pedestals with 4 bolt flat base directly.
For Quickfix mount and all Sachtler pedestals the Multi
Disc from the Sachtler accessory range is required.
5.4 Conversion of the Video 60 Plus EFP to include
Mitchell base
Especially in the United States the Mitchell mount is wide-
ly spread.To convert put the fluid head upside down, so
that you can access the bottom of the head.Next to the
centre bolt you will see 4 allen screws. Those have to be
unscrewed and the whole piece has to be removed.Take
he Mitchell adapter piece with locking knob from the
Sachtler accessory range.Place the adapter piece into the
recess at the bottom side of the head.
