- 1 -
Video 60 Plus EFP Manual
1 Safety instructions
Á
When the camera is mounted, the clamping screw of the
Video 60 Plus EFP must only be released if camera and tri-
pod are secured against falling over.
Á
When placing the camera plate into the Video 60 Plus EFP,
make sure not to hold fingers within the range of the locking
lever, since it will snap back.
Á
When releasing the vertical brake make sure that the came-
ra is secured against any sudden movement.
Á
Do not operate the fluid head upside down without the
necessary securing devices, i.e. ropes etc.
Á
Before transport reset fluid damping to “0”
2 Operating elements
Safety lock of Touch
& Go system
Horizontal brake
Horizontal setting of
fluid damping
Counterbalance knob
Touch bubble
Flange for view
finder extension
Lock of the came-
ra balance plate
Clamp screws
of fluid head
Rosette for
mounting panbar
