Sachtler Video 60 Plus EFP Fluid Head (150mm Ball Base) - Supports 35-145 lbs User Manual
Page 3
- I -
Table of contents
1
Safety instructions ...............................................................1
2
Operating elements..............................................................1
3
Operation .............................................................................2
3.1 Levelling of the fluid head............................................2
3.2 Removing of the camera plate ...................................3
3.3 Mounting of the camera...............................................3
3.4 Removing of the camera..............................................3
3.5 Positioning of the camera ............................................4
3.6 Adjusting the camera’s counterbalance ......................5
3.7 Setting of the Damping................................................7
3.8 Brakes ..........................................................................7
3.9 Support for view finder extension................................7
3.10 Change of the batteries ...............................................7
3.11 Transport setting of damping, counterbalance
and brakes ...................................................................8
4. Technical specifications.......................................................9
4.1 General data ................................................................9
4.2 Dimensions ..................................................................9
5
The modular system ..........................................................10
5.1 Conversion of the Video 60 Plus EFP to include
V-shaped wedge plate...............................................10
5.2 Conversion of pan bars and rosette ..........................11
5.3 Conversion of Video 60 Plus EFP to include flat base ..11
5.4 Conversion of the Video 60 Plus EFP to include
Mitchell base..............................................................11
6
Accessories................................................................12
7
Warranty .............................................................................12
