Manual Video 60 Plus EFP
- 2 -
Vertical brake
tilt safety lock
Vertical setting
of fluid damping
Locking lever of Touch
& Go System
Lever for ½ Counterbalance springs
Battery holder
for touch bubble
Spindle of sliding-balance plate
3 Operation
3.1 Levelling of the fluid head
The Video 60 Plus EFP has a bubble to facilitate levelling.
Apply the vertical brake of the Video 60 Plus EFP and hold
the camera with one hand. Open the clamping screw of
the fluid head and move the head in such a way, that the
bubble moves into the levels black circle. Tighten the
clamping screw firmly.
Touch Bubble
The Video 60 Plus EFP has a self illuminating spirit bubble
which allows easy levelling even under unfavourable
lighting conditions.
The illumination is activated by strong tapping on the bub-
ble. The bubble will light up to 45 seconds.
