Manual Video 60 Plus EFP
- 10 -
5 The modular system
Due to the Video 60 Plus EFP fluid heads modular design you
may perform certain modifications yourself. In order to safe
time you can do all work with an allen wrench #4 unless other-
wise specified.
The following modifications can be performed:
Á
Conversion of the Video 60 Plus EFP to include V-shaped
wedge plate
Á
Conversion of pan bars and rosette
Á
Conversion of Video 60 Plus EFP to include flat base
Á
Conversion of the Video 60 Plus EFP to include Mitchell
5.1 Conversion of the Video 60 Plus EFP to include
V-shaped wedge plate
Open the 2 screws of the spindle fixation with allen
wrench # 2 and remove the fixation piece.
Open the lock of the balance plate by pushing back red
lever underneath the balance plate as far as possible.
Keep on turning the knob of the spindle to the left until
you can remove the balance plate.
Loosen the 4 screws (now visible) of the base plate under-
neath and remove it.
Take at your hand the Studio set up from the Sachtler
accessory range.
With this set up it is likely that you have to remove the
balance plate from the base plate first. Therefore you have
to remove the fixation screw in the spindles top end. Open
the lock of the balance plate and keep on turning the knob
of the spindle to the left until you can remove the balance
plate.
Screw the base plate onto the head. Fasten the allen scr-
ews hand-tight.
