Henny Penny OFE- 290 - Manual (Page 12)

Model OFE- 290
3-11. FILTER PUMP MOTOR The filter pump motor is equipped with a manual reset button,
PROTECTOR-MANUAL located on the rear of the motor, in case the motor overheats. If
RESET motor won’t run, wait about 5 minutes before attempting to reset this
protective device to allow motor to cool. Remove the access panel
on the left side panel of the unit to reset the button. It takes some
effort to reset, and a screwdriver can be used to help reset the
button.
To prevent burns caused by splashing shortening, turn
the unit’s main power switch to the OFF position before
resetting the filter pump motor’s manual reset
protection device.
3-12. REGULAR MAINTENANCE The Henny Penny open fryer does require care and proper mainte-
nance. The table below provides a summary of scheduled mainte-
nance. The following paragraphs provide step-by-step preventive
maintenance procedures to be performed by the operator.
Procedure Frequency
Filtering of shortening See KFC’s Standards Library
Changing of shortening See KFC’s Standards Library
Changing the filter envelope See KFC’s Standards Library
Cleaning the frypot See KFC’s Standards Library
Cleaning Nylattrons Monthly-see below
Lubricate lid rollers Annually-see below
Inspect Counter-Weight Cables Annually-see below
3-13. PREVENTIVE Cleaning Nylatrons
MAINTENANCE
1. Spray Henny Penny biodegradable, food safe, foaming
degreaser (part no. 12226) on Nylatrons.
2. Raise lid up and down several times to spread the degreaser.
3. Wipe Nylatrons to remove food soil, grease, and degreaser
residue.
Lubricating Lid Rollers
The lid rollers, in the back of the fryer, should be lubricated at
least once a year, to allow the lid easy movement.
1. Remove the back shroud of the fryer.
2. Using spindle lube, part number 12124, place a small amount
of lube on both top and bottom rollers. Make sure to lube
both left and right rollers.
3-12 1012
