Buyers 5412000 User Manual
Page 2
2
Step 2: Assemble driver-side panel #3018663
and center (door) panel #3018244.
As shown in Figure 3., align and bolt together the
center (door) panel and the driver-side panel using
the following hardware:
(8) #10-24 Screws
(8) #10-24 Lock Nuts
Note: Use the smaller hole diameter.
See Detail A.
Figure 3
See Detail A
Detail A.
Step 3: Assemble passenger-side panel
#3018245
Align and bolt together the passenger-side
panel to the existing assembly using the
following hardware:
(8) #10-24 Screws
(8) #10-24 Lock Nuts
Note: If your van is equipped with a sliding
door, you may need to remove the top right
corner portion of the passenger-side panel.
See Figure 4.
Step 4: Place the assembled unit inside
the van and roughly place into position.
Figure 4
This portion may need
to be removed for sliding doors.
#3018663
#3018244
#3018245
