Pin Descriptions
Pin Number Pin Name Function
1 CPC This pin connects a capacitor to GND for output cable compensation
2 FB The voltage feedback from auxiliary winding
3 VCC This pin receives rectified voltage from the auxiliary winding of the transformer
4 CS Current sense for primary side of transformer
5, 6 C This pin is connected with an internal power BJT’s collector
7 GND This pin is the signal reference ground
Functional Block Diagram
Regulator
&
Bias
OVP
OCkP
OTP
PFM
UVLO
CV_ctrl
PFM
Driver
R Q
S
R Q
S
FB
CS
CPC
VCC
CS
GND
Constant Voltage Control
Cable Compensation
Constant Current
Control
