9

Names of the Parts

Screw Cover

Table

Screw Cover

X-Y cable

X direction

datum surface

Connector Joint

Connector BOX

X-Y cable

Connector Joint Details

M cable

PG cable

Frame

X2-axis (slave axis)

X1-axis (master axis)

Y-axis

Z-axis

Z-axis cover

Y direction

datum surface

Screw Cover
