Interior, Front seats, Accessing the rear seat – Volvo 2009 C70 User Manual
Page 92: Manual seat, 04 interior
04
92
Manual seat adjustment
The driver's and passenger's seats can be
adjusted in a number of ways to provide a
comfortable driving and sitting position.
Forward-rearward: Pull the lever up and
slide the seat to the position of your choice.
Use this control to raise or lower the front
edge of the seat cushion.
Use this control to raise or lower the rear
edge of the seat cushion.
Turn this knob (option on some passeng-
er's seats) to adjust the firmness of the
lumbar support
1
.
Turn this knob to adjust the backrest tilt.
Control panel for power seats.
•
Do not adjust the seat while driving.
•
Adjust the driver’s seat and seat belt
(see page 18) before driving. The seat
should be adjusted so that the brake
pedal can be depressed fully.
•
Position the seat as far rearward as
comfort and control allow.
Accessing the rear seat
Seat access buttons (power seat shown)
Seat adjustment handle
Seat adjustment button
Manual seat
Moving the seat forward:
1. Remove the seat belt from its guide (see
2. Pull up handle 1 (see the illustration), hold
it up, and fold the backrest forward until it
locks in position.
3. Slide the seat forward.
1
Also applies to the optional power seat.
