Page 23
17
Indicator and warning lights
1
Turn signal, left
2
Turn signal, right
3
Roll Over Protection system - ROPS
4
Low washer fluid level
If the lamp illuminates when the engine is
running, there is only about 1/2 - 1 US qt.
remaining in the washer fluid reservoir.
5
Low fuel level
When the lamp glows, only about 1.8 US gals.
(8 liters) of fuel remain. If the ignition is
switched on while refuelling, the gauge may
read inaccurately for up to 25 minutes.
6
Rear fog light
7
High beams
8
Trunk open
9
Bulb failure warning sensor
10 (Not in use)
11 Electronic Throttle System
(ETS)
12 SRS indicator lamp
13 Generator not charging
14 Low engine oil pressure
15 Brake warning light
16 Parking brake applied
17 ABS-system
18 Transmission mode:
Indicates W" if winter/wet driving mode is
active, or indicates currently selected low gear.
19 Low coolant level
20 Stability and Traction Control
(STC) System
21 Malfunction indicator lamp
(See page 18 for more information)
22 Service reminder indicator
3800738A
H
M
SRS
KM/H
VICE
SER-
BRAKE
BRAKE
PARK
CHECK
ENGINE
22
21
20
19
18
17
16
15
14
13
ABS
MAX
MPH
12
11
10
9
8
7
6
5
4
3
2
1
ROPS
ETS
