FORM NO. L-20016-X-1209
GENERAL SPECIFICATIONS
GENERAL SAFETy PRECAUTIONS
CAUTION
Use lifting aids and proper lifting
techniques when installing, removing,
or placing this product in service.
WARNING
This product is capable of emitting
a spark if misused therefore is not
recommended for use in any explosive
environment.
CAUTION
This product has possible pinch
points. Care should be taken when
interacting with this product.
Specifications
Torque:
Clutch up to 294 Nm ( 2600 in-lbs)
Brake up to 316 Nm (2800 in-lbs)
Actuation Pressure:
1 - 5.5 bar (14.5 - 80 psi)
Service Temperature: 4.5 - 104 C (40 - 220 F)
Approximate Weight:
Up to 64.5 kg (142 lbs)
CAUTION
Use appropriate guarding for moving
components. Failure to guard could
result in serious bodily injury.
CAUTION
Watch for sharp features when
interacting with this product. The parts
have complex shapes and machined
edges.
WARNING
Ensure proper guarding of the product is
used. Nexen recommends the machine
builder design guarding in compliance
with OSHA 29 CFR 1910 “Occupational
Safety and Health Hazards”.
CAUTION
Surface temperature may exceed
safe handling limits during
operation. Do not touch.
CAUTION
Use appropriate guarding for moving
components. Failure to guard could
result in serious bodily injury.
