Changing the rear bulbs
Opening and closing the side trim
panels
You must open the side trim panel in the
cargo compartment before you can change
the bulbs in the tail lamps.
Left-hand side trim panel
Right-hand side trim panel
X To open: turn release knob : 90° in the
direction of the arrow and remove side trim
panel ;.
X To close: insert side trim panel ; and turn
release knob : 90° in the opposite
direction to the arrow.
Tail lamps
Turn signal lamp/tail lamp and brake
lamp
X Switch off the lights.
X Open the cargo compartment.
X Open the side trim panel ( Y page 109).
X Press retaining lugs : simultaneously in
the direction of the arrow and pull the bulb
holder out.
Bulb holder
:
Tail lamp/brake lamp 3
;
Inoperative lamps (vehicles without LEDs)
=
Side marker lamp (vehicles without LEDs)
X Lightly press the corresponding bulb into
the holder, turn it counter-clockwise and
remove it from the bulb holder.
X Insert the corresponding new bulb into the
bulb holder and turn it clockwise.
3 Vehicles with LEDs: turn signal/brake light only.
Replacing bulbs
109
Lights and windshield wipers
