Mercedes-Benz 2012 B Class - Manual (Page 246)

:
Bag hook
Cargo compartment cover
Important safety notes
G
WARNING
On its own, the cargo compartment cover
cannot secure or restrain heavy objects,
items of luggage and heavy loads. You could
be hit by an unsecured load during sudden
changes in direction, braking or in the event
of an accident. There is an increased risk of
injury or even fatal injury.
Always store objects so that they cannot be
flung around. Secure objects, luggage or
loads against slipping or tipping over, e.g. by
using tie downs, even if you are using the
cargo compartment cover.
! When loading the vehicle, make sure that
you do not stack the load in the cargo
compartment higher than the lower edge of
the side windows. Do not place heavy
objects on top of the cargo compartment
cover.
! When removing and installing the cargo
compartment cover, ensure that its end
caps do not scrape the light-colored parts
of the vehicle.
The cargo compartment cover is located
behind the rear bench seat backrest.
Extending/retracting the cargo
compartment cover
X To extend: pull the cargo compartment
cover back by grab handle : and clip it
into retainers ; on the left and right.
X To retract: unhook the cargo compartment
cover from retainers ; on the left and right
and guide it forwards by grab handle :
until it is fully retracted.
Installing/removing the cargo
compartment cover
X To remove: make sure that the cargo
compartment cover is rolled up.
X Push in the end cap of cargo compartment
cover : in the direction of the arrow on
the right or left side using grip =.
X Push cargo compartment cover : into
opposite anchorage ;.
X Remove cargo compartment cover :
upwards.
244
Stowage areas
Stowage and features
