Subaru 2009 Tribeca - Manual (Page 380)

12-6
Specifications
Fuse
panel
Fuse
rating
Circuit
13 20A . Cargo socket
14 15A . Position light
. Tail light
. Rear combination light
15 Empty
16 10A . Illumination
17 15A . Seat heaters
18 10A . Back-up light
19 7.5A
. Headlight right side re-
lay
20 Empty
21 7.5A . Starter relay
22 15A . Air conditioner
. Rear window defogger
relay coil
23 15A . Rear wiper
. Rear window washer
24 15A . Audio unit
25 15A
. SRS airbag system
(main)
26 7.5A . Power window relay
27 15A . Rear blower fan
Fuse
panel
Fuse
rating
Circuit
28 15A . Rear blower fan
29 15A . Fog light
30 30A . Front wiper
31 7.5A . Auto air conditioner unit
. Integrated unit
32 7.5A . Headlight left side relay
33 7.5A
. Vehicle dynamics con-
trol unit
