AIR CONDITIONER OPERATION

Start the engine, turn the fan control dial to the

desired position, and push in the

button to

activate the air conditioner. When the air condi-

tioner is on, cooling and dehumidifying functions

are added to the heater operation.
The air conditioner cooling function oper-
ates only when the engine is running.

Cooling

This mode is used to cool and dehumidify the air.

1. Push the

button to the OFF position.

2. Turn the air flow control dial to the

position.

3. Turn the fan control dial to the desired posi-

tion.

4. Push the

button. The indicator light

on the

button will come on. (A/C will

appear on the display, if so equipped.)

5. Turn the temperature control dial to the de-

sired position.

● For quick cooling when the outside tem-

perature is high, push the

button to

the ON position. The indicator light on

the

button will come on. (

will

appear on the display, if so equipped.) Be

sure to return the

to the OFF position

for normal cooling. The indicator light on

the

button will go off. (

will ap-

pear on the display, if so equipped.) You may

also select MAX A/C for quick cooling.

Dehumidified heating

This mode is used to heat and dehumidify the air.

1. Push the

button to the OFF position.

The indicator light on the

button will

go off. (

will appear on the display, if so

equipped.)

2. Turn the air flow control dial to the

position.

3. Turn the fan control dial to the desired posi-

tion.

4. Push the

button on. The indicator

light on the

button will come on. (A/C

will appear on the display, if so equipped.)

5. Turn the temperature control dial to the de-

sired position.

Operating tips

● Keep the windows closed while the air con-

ditioner is in operation.

● After parking in the sun, drive for 2 or 3

minutes with the windows open to vent hot

air from the passenger compartment. Then,

close the windows. This allows the air con-

ditioner to cool the interior more quickly.

The air conditioning system should be

operated for approximately 10 minutes

at least once a month. This helps pre-

vent damage to the system due to lack

of lubrication.

● A visible mist may be seen coming from the

ventilators in hot, humid conditions as the air

is cooled rapidly. This does not indicate a

malfunction.

If the engine coolant temperature

gauge indicates engine coolant tem-

perature over the normal range, turn

the air conditioner off. See “If your

vehicle overheats” in the “In case of

emergency” section of this manual.

AIR FLOW CHARTS

The following charts show the button and dial

positions for MAXIMUM AND QUICK heating,

cooling or defrosting. For additional information

on heating and cooling see “Heater and air con-

ditioner” in this section. The air recirculation

(

) button should always be in the OFF

position for heating and defrosting.

Display screen, heater, air conditioner, audio and phone systems

4-31
