30
Rev.A
920-0090
SSM23Q/IP Hardware Manual
5.3 Torque-Speed Curves
Note: all torque curves were measured at 20,000 steps/rev.
Note: 5 amp rating is continuous, 7.5 amp rating is boost
Continuous
Boost 24V 48V 70V
24V 48V 70V
0
0.5
1
1.5
2
2.5
0 10 20 30 40 50
To
rq
ue
(N·m)
Speed(rps)
SSM23Q/IP-3EG
0
0.3
0.6
0.9
1.2
1.5
0 10 20 30 40 50
To
rq
ue
(N·m)
Speed(rps)
Continuous
Boost 24V 48V 70V
24V 48V 70V
SSM23Q/IP-2EG
0
0.5
1
1.5
2
2.5
3
3.5
0 10 20 30 40 50
To
rq
ue
(N
.m
)
Speed(rps)
SSM23Q/IP-4EG 24V 48V 70V
24V 48V 70V
Continuous
Boost
