Fig. 7-a
Section 7
ENGINE CONTROL COMPUTER REMOVAL AND MODIFICATION
7.1 ENGINE CONTROL COMPUTER
REMOVAL AND MODIFICATION
B. Pull the harnesses down and out of the way,
creating unobstructed access to the comput-
er. Remove the 7/32 screw that secures the
retention strap (see Fig. 7-b) and pull the
computer out of the foot well.(see Fig. 7-c.)
A. Remove the passenger side door sill plate,
followed by the passenger side kick panel.
This will reveal the engine control computer
and its harnesses. The harnesses are secured
using clips, which are attached to a small
metal bracket. Pull the harnesses off the
bracket, then remove the two 7/32-inch bolts
that secure the bracket itself. Remove the
bracket.(See Fig. 7-a.)
Fig. 7-b
Fig. 7-c
