Paxton Superchargers Dodge Durango - Manual (Page 24)

A-6 P/N: 4809632
©2002 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
25SEP02 v1.0 Dodge Durango(4809632v1.0)
Appendix 4
SCALE:
SIZE
DWG.
D
SHEET
1
O
F
1
REV
.
DA
TE
APPROV
ALS
DRA
WN
ENGINEERING R&D
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE:
DECIMALS:
.XX
± .01
.XXX
± .005
MA
TERIAL
FINISH
NONE
SEE P
A
R
TS LIST
DO NOT SCALE DRA
WING
WEIGHT
3.8 LBS
1:2
1015934
NC
FRACTIONS:
ANGLES:
± 1/16 ± 1/2•
ASY
, AIR INT
AKE
APPR.
1/10/01
00/01 4.7L DODGE
A. PROCTOR
1300 BEACON PLACE OXNARD, CA 93033 TEL: (805) 604-1336 F
AX: (805) 604-1337
CAD GENERA
TED DRA
WING,
DO NOT MANUALL
Y UPDA
TE
ITEM NO.
QTY
.
P
AR
T NO.
DESCRIPTION
1 2 3 4 5 6 7 8 9
10
1 1 1 3 3 1 1 1 1 1
8001997-1 8002105 4808802 2717001 4828900 4810168 2735411 1053410 1053430 2755500
HSG, FIL
TER MODIFIED
RING, FIL
TER RET
AINER
FIL
TER, AIR HIGH FLOW
W
ASHER, #10 INT LOCK
SCREW
, P
AN HD, 10-24UNC-2A X .38 LG.
TUBE, AIR INT
AKE
HOSE, STEP
, 4.00 X 3.50
CLAMP
, HOSE #56
CLAMP
, HOSE #64
FTG, NIPPLE 1/2 HOSE
9
7
TO S/C ASY
8
6
TO CRANKCASE VENT
TO COMPRESSOR BY
-P
ASS ASY
10
2
X 3
5
4
3
1
