Paxton Superchargers Dodge Durango - Manual (Page 31)

A-13 P/N: 4809632
©2002 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
25SEP02 v1.0 Dodge Durango(4809632v1.0)
ITEM NO.
QTY
.
P
AR
T NO.
DESCRIPTION
1 2 3 4
1 2 2 4
4PCE010-060 7A250-074 7F250-021 7J250-022
BRKT
, MTG, CRUISE CONTROL
SCREW
, HXHD, 1/4-20UNC-2A X .75 LG., STEEL GR5
NUT
, HXHD, 1/4-20UNC-2B STEEL GR5 WITH NYLOK
W
ASHER, 1/4 FLA
T SAE
SCALE:
SIZE
DWG.
C
SHEET
1
O
F
1
REV
.
DA
TE
APPROV
ALS
DRA
WN
ENGINEERING R&D
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE:
DECIMALS:
.XX
± .01
.XXX
± .005
MA
TERIAL
FINISH
NONE
SEE P
A
R
TS LIST
DO NOT SCALE DRA
WING
WEIGHT
.3 LBS
1.5:1
1020216
A
FRACTIONS:
ANGLES:
± 1/16 ± 1/2•
ASY
, CRUISE CONTROL RELOCA
TION
APPR.
G. COMPTON
8/14/01
2000/2001 4.7L DODGE DURANGO
A. PROCTOR G. COMPTON
10/4/01 2/12/01
1300 BEACON PLACE OXNARD, CA 93033 TEL: (805) 604-1336 F
AX: (805) 604-1337
CAD GENERA
TED DRA
WING,
DO NOT MANUALL
Y UPDA
TE
L. KECK
2/12/01
2x
2
4
2x
3
4
1
Appendix 11
