Uhf vhf – Televes KIT DIGINOVA BOSS ANTENNA FM/BIII/UHF G-2/10/22dBi User Manual
Page 20
20
20
Sygnał
Signal
Segnale
Sinal
Signal
Señal
Signal
FM
BIII
UHF
21-60
Maksymalny
wzmocnienie
Gain
maximal
Guadagno
massimo
Ganho
máximo
Maximaler
Gewinn
Ganancia
máxima
Maximum
gain
dBi
BOSS OFF
-2
4 ... 7
BOSS ON
-2
10
19 ... 22
Współczynnik szumów
Facteur de bruit
Figura di rumore
Figura ruido
Rauschmaß
Figura ruido
Noise figure
dB
-
3
2
Poziom wyjściowy
Niveau sortie
Livello uscita
Nivel saída
Ausgangspegel
Nivel salida
Output level
dBµV
(DIN45004B)
-
Autoregul.
Zasilanie
Tension d´aliment. Alimentazione
Alimentação
Spannungs-
versorgung
Alimentación
Power supply
V
12 - 24
Maks. prąd
Courant max.
Assorbimento
Corrente máx.
Stromverbrauch
Corriente máx.
Max. current
mA
32@12Vdc - 37@24Vdc
Stopień ochrony
Indice protection
Indice protezione Indice protecção Schutzklasse
Ind. protección
Protection level
IP
53
Obciążalność wiatrem
Resist. vent.
Carico del vento
Carga vento
Windlast
Carga al viento
Wind load
N
69.6 (@ 130 Km/h)
95.7 (@ 150 Km/h)
Waga
Poids
Peso
Peso
Gewicht
Peso
Weight
g
1500
Wymiary
Dimensions
Dimensioni
Dimensões
Abmessungen
Dimensiones
Dimensions
mm
420 x 315 x 75
Características técnicas / Características tecnicas / Caractéristiques techniques / Technical specifications / Caratteristiche
tecniche / Specyfikacja techniczna / Technische Daten
Radiación / Radiação / Radiation / Radiation / Radiazione / Promieniowanie / Strahlungsdiagramm
0
90
180
270
UHF
0
90
180
270
BIII
0
90
180
270
UHF
0
90
180
270
BIII
UHF
VHF
