Connecting an A/V Receiver — Audio
Connecting an A/V Receiver — Audio
There are several options available for audio connections to your A/V receiver:
•
Digital audio (OPTICAL S/PDIF)
•
Digital audio (COAXIAL S/PDIF)
•
Stereo audio (AUDIO L/R)
If your A/V receiver supports it, the optical (S/PDIF) or coaxial (S/PDIF) digital audio
outputs may be used in place of the stereo audio outputs (audio L/R). These outputs
offer a higher level of audio quality, including support for Dolby Digital audio.
•
Digital audio optical (S/PDIF) — Connect an optical cable to the digital audio optical
out connector on the DCX set-top and the digital audio optical in connector on the
A/V receiver.
•
Digital audio coaxial (S/PDIF) — Connect a digital audio cable to the digital audio
coaxial out connector on the DCX set-top and the digital audio coaxial input
connector on the A/V receiver.
•
Stereo audio — Connect a stereo audio cable to the audio L/R output connectors on
the DCX set-top and the audio L/R input connectors on the A/V receiver.
For information on configuring your DCX set-top settings, see
