Application Development Overview
PCIE-8120 Installation and Use (6806800R89C) 43
5.3.1 Octasic DSP Firmware image creation
Octasic provides an image creation tool, that allows the user to specify configuration options
and the application object file to be included when creating the bootfile. The DSP firmware
image creation application is provided with the package:
File Name:
oct2200_boot_img_gen
File Location:
/opt/octasic/bin
Syntax:
oct2200_boot_img_gen <input file> <output file>
Input file:
simplified CSV description file created for PCIE-8120.
Output file: firmware image file created
Example:
# cd /opt/octasic/hardware/octvoc2/oct2200/bootfile
# /
opt/octasic/bin/oct2200_boot_img_gen
octvocmgw.citadelle.csv oct2200citadelle.img
Always use the octvocmgw.citadelle.csv file provided with the RPM, for creating DSP
images for PCIE-8120. To set up the card with its board-specific hardware
octvocmgw.citadelle.csv
file is required.
