PCIE-8120 External Connectors
PCIE-8120 Installation and Use (6806800R89C) 53
A.4 P2 External ATX 6-Pin Power Connector (only on
-N versions)
An ATX 6pin power connector is available at the P2 location for the NEBS optimized (-N)
variants of the PCIE-8120 card. As under NEBS exceptional operation conditions, the current
drawing from the slot connector could exceed the maximum allowed per pin current. The -N
variants receive 12V supply power exclusively from the P2 connector.
For more details on the P2 connector, see PCI Express x16 Graphics 150W-ATX Specification
document listed in
Table "Related Specifications" on page 91 .
A.5 Debug Connectors
The PCIE-8120card is equipped with several debug ports. The debug ports allow
DSP/MFA,CPLD/FPGA programming, and JTAG/BSCAN functionality.
 P4201 serial port MFA: RS232 style debug port for the MFA application.
 P5001 OCT-SDBI2 debug port: The Octasic Pod requires an adapter cable for the micro-
header.
The connector style is a 16-pin, 1.27 mm pitch micro-header.
For more information, contact Artesyn and refer to part number 30NL9302D24.
Table A-2 ATX PWR Pinout
Pin No. Description
1 +12V
2 +12V
3 +12V
4 Ground
5 Sense
6 Ground
