PCIE-8120 External Connectors
PCIE-8120 Installation and Use (6806800R89C)
54
A.6
P3 Fan Unit Connector (Optional component)
The PCIE-8120 card supports a heat sink assembly that is equipped with a fan or blower unit. A
three pin header provides 12V supply for this purpose. An additional buffer circuitry allows for
PWM fan speed control via the CPLD.
Molex 3 pin header 53398-0371 “pico-blade” series.
12V /200mA max. PWM drive capability for a 2.4W class fan/blower unit or hi-impedance
2k/20k PWM control input.
Table A-3 Opt. fan unit connector Pinout
Pin-No.
Description
1
12V main supply (1A max.)
2
FAN_PWM_CTRL (3.3V logic level PWM control or 12V/200mA PWM
driver)
3
GND main supply
