Application Development Overview
PCIE-8120 Installation and Use (6806800R89C)
45
The file octvc1_config.arg located in folder octvocmgw specifies the hardware specifics
of the PCIE-8120:
<EthernetPort PortNum="0">
<PortInterface Value="EMAC2"/>
<EthernetPort PortNum="1">
<PortInterface Value="EMAC0"/>
<TdmModule>
<TdmDisabledFrameSrcValue="0"/>
<FramePolarity Value=""/>
<FrameSamplingMode Value=""/>
<DataSamplingMode Value=""/>
<FromTdmTsstBufferSizeMs Value=""/>
<ToTdmTsstBufferSizeMs Value=""/>
<FromTdmBitOffset Value=""/>
<ToTdmBitOffset Value=""/>
<NumStream Value=""/>
<StreamFrequency Value=""/>
<Loopback Value=""/>
<TdmDataResolution Value=""/>
</TdmModule>
<CoreAllocation>
<TdmDriverEnable Value="0"/>
<lineEchoCancellerEnable Value="0"/>
</CoreAllocation>
<MaxNumBuffer Value="32"/>
There are configuration parameters that should be customized with respect to their
application. An example is given below:
<MaxNumTerm Value="800"/>
<MaxNumEchoTerm Value="400"/>
<MaxNumConferenceParticipants Value="128"/>
<MaxNumVideoRxQcif Value="32"/>
<MaxNumVideoRxCif Value="4"/>
