IO Data Mapping
13
IPxxxx-B520
2.7 IP4xxx-B520
IO Assembly Instances
Input Data (1 Byte)
IO Assembly Instances
Number
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
151
0
Reserved Reserved Reserved Reserved Status
Analog
Output4
Status
Analog
Output3
Status
Analog
Output2
Status
Analog
Output1
Output Data (8 Byte)
IO Assembly Instances
Number
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
160
0
Low Byte Analog Output 1
1
High Byte Analog Output 1
2
Low Byte Analog Output 2
3
High Byte Analog Output 2
4
Low Byte Analog Output 3
5
High Byte Analog Output 3
6
Low Byte Analog Output 4
7
High Byte Analog Output 4
Mapping IO Assembly Data to DeviceNet Objects
Data Component Name Class
Instance Attribute
Name
Number
Name
Number
Analog Output n
Analog Output Point
11
1 – 4
Value
3
Status Analog Output n
Analog Output Point
11
1 – 4
Status
4
