Introduction

IPxxxx-B520

6

Introduction


IPxxxx-B520

The purpose of this document is to provide DeviceNet Specific Information
needed to run Beckhoff IPxxxx-B520 fieldbus boxes in a DeviceNet Net-
work.




DeviceNet Characteristics

Characteristic

Description

DeviceNet Functionality

Group Two Only Slave for DeviceNet Master / Scanner

IO – Modes

Polling, Bit Strobe, Change of State / Cyclic

Configuration

Switches (Node Address) , Configuration Objects, Electronic Data Sheet
(EDS)

LEDs

Module / Network Status LED, Vendor Specific IO LEDs

Electronic Data Sheet

Electronic Data Sheet for each type of IPxxxx-bB520 (www.beckhoff.com)

Connector

Sealed Micro Style Connector

Baud Rates

125 Kbaud, 250 Kbaud, 500 Kbaud
