CDM-750 Advanced High-Speed Trunking Modem Revision 2
Front Panel Operation MN-CDM750
5–52
5.2.5 SELECT: Info (Information)
INFO screens provide read‐only information on the modem’s current configuration without
risking inadvertent changes.
Info: ID Intf Tx Rx Clocks ACM CnC
Misc Mask Remote Comp
Use the
◄ ► arrow keys to select ID, Intf, Tx, Rx, Clocks, ACM, CnC, Misc, Mask, Remote, or
Comp, and then press ENTER.
Typical for all INFO screens, Press ENTER or CLEAR to return to the SELECT: INFO menu.
5.2.5.1 Info: ID
Modem Circuit ID:
CIRCUIT_ID_TEST_MESSAGE
This screen displays the user‐defined Circuit ID string (24 characters maximum) created
previously using the Utility ÆCircuit‐ID submenu.
5.2.5.2 Info: Intf
Chapter 3. REAR PANEL CONNECTORS provides detailed information about all of
the interfaces that are available on CDM‐750 rear panel.
INTF: PIIC1=G703 PIIC2=NONE
GBEI1=Auto GBEI2=Auto OptInst:N
This screen displays the presence of/operational parameters for:
• The optional dual Plug‐In‐Interface Card slots – Referred to in this chapter as PIIC1 and
PIIC2.
• The dual Gigabit Ethernet ports – J5 | DATA, also referred to in this chapter as GBE1;
and J6 | DATA, referred to as GBE2.
• The optional Optical Gigabit Ethernet Interface Module as installed in the J7 | OPTICAL
socket.
