LBC-4000 L-Band Up/Down Converter System with Ethernet

Revision 2

Updating Firmware

MN-LBC4000A

4–3

times to get  to the top‐level display if not visible. Additionally, review the information
provided on the UTILITY Æ FIRMWAREÆ INFO Æ IMAGE#1 or IMAGE#2 screens.



• On the user PC – Use the terminal emulator program to log in to the LBC‐4000, and then

use Serial Remote Control to obtain, and make note of, the firmware information:

Type  (without  the  quotes)  “<0/FRW?<cr>”  at  the  command  prompt  to  query  the
LBC‐4000 for its Firmware Number and Release Version.



  See  Chapter  6.  SERIAL‐BASED  REMOTE  PRODUCT  MANAGEMENT  for

information and instructions on using Serial Remote Control.



• On the user PC – Use the LBC‐4000 Web Server Interface.


Use a Web browser (e.g., Internet Explorer)
to  log  in  to  the  LBC‐4000  Web  Server
Interface

and

review

the

Firmware

Information  section  of  the  ‘Config  |  Utility’
page.  There,  make  note  of  the  firmware
loads:






See  Chapter  5.  ETHERNET‐BASED  REMOTE  PRODUCT  MANAGEMENT  for
information and instructions on using the LBC‐4000 Web Server Interface.



2. Next,  create  a  temporary  folder  (subdirectory)  on  the  user  PC  for  the  firmware  archive

download.




• Drive letter ‘c:’ is used in these examples. Any valid, writable drive letter can be

used.


• Typical for all tasks: Type the command without quotes, and then press Enter to

execute.



There are several ways the user may use create a temporary folder on a Windows‐based PC:



A. Use the Windows Desktop to create and rename the temporary folder.


• Right‐click anywhere on the desktop to open the popup submenu, and then select

New > Folder to create the new, temporary folder on the desktop.


• Right‐click on the new folder and then select ‘Rename’ from the popup submenu.

Rename this folder to "temp" or some other convenient, unused name.
