Display is stuck on bright or dim. · Check Manual/Auto dimming in Venus 1500
software.
· Check light detector cable.
· Check light detector for obstructions.
· Replace the light detector.
· Replace the controller.
4.10 Boot Up Initialization Information
Every time the display is powered up, the display will run through an initialization in which it will
display the following:
1. Output Test (DDDs)
2. Product Name (Galaxy)
3. Display Size (Row x Column)
4. Firmware Number (ED-12699)
5. Firmware Revision (Rev X.XX)
6. COM1
Configuration (C1: V15/RTD)
7. COM2 Configuration (C2: None)
8. Line Frequency (60 Hz)
9. Hardware Address (HW: XX)
10. Software Address (SW: XX)
11. Display Name
12. Modem (If modem is present)
4.11 Replacement Parts List
The following tables contain some of the items that may need to be replaced in these displays over a
period of time. Many of the parts within the display also list their part numbers on labels affixed to
them.
To prevent theft Daktronics recommends purchasing a lockable cabinet to store manuals and
replacement/spare parts.
Part Description Part Number
Controller II, 48x168, Louvered Galaxy 0A-1146-0067
Module, 2R2G2B (1:1) 8x8 (30x70) Type 1 0A-1208-2551
Power Supply Assembly, 2 A-1633, 1 A-1591 0A-1241-4001 &
0A-1213-4034
Thermostat Enclosure 85-70-9L 0A-1213-4024
Light Level Detector; 34mm 0A-1215-4001
Filter; Air, Gasket, 7.50” x 13.50” x .88” EN-1774
Fan; 250CFM, 115VAC, 0.65A, 5.84x6.0” B-1019
Transformer; Pri 115V, Sec [email protected] (120V Displays) T-1072
Transformer; 115/240V Pri [email protected] (240V Displays) T-1106
Filter, RFI Line 10 AMP 120 VAC Z-1007
Fan Finger Guard (for B-1019 fan) HS-1130
Fuse Holder; 1 Pos. Pnl Mt. ¼” X-1032
Thermostat; SPST NO Close 85 Open 70 S-1144
Modem Board; 232 Coated 0P-1146-0003
Fiber Board; RS232 to Fiber, 12V 0P-1127-0024
Jack; 6-Pin Female for Modem J-1094
Cable; 18” RJ11; 6-Cond. 0A-1137-0160
Signal Converter (RS232/RS422) 0A-1127-0237
Maintenance & 4-9
Troubleshooting
