BIOS Setup
SATA Configuration
This section is used to configure SATA functions.
(1) IDE Mode.
(2) AHCI Mode.
(3) RAID Mode.
BIOS SETUP UTILITY
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
SATA Configuration
SATA Port 0
SATA Port 1
SATA Port 4
SATA Port 5
SATA Mode
Serial-ATA Controller 0
Serial-ATA Controller 1
Advanced
SATA Mode
IDE Mode
This option configures the Serial ATA drives as Parallel ATA storage devices.
AHCI Mode
This option allows the Serial ATA devices to use AHCI (Advanced Host Con-
troller Interface).
RAID Mode
This option allows you to create RAID or Intel Matrix Storage configuration on
Serial ATA devices.
Serial-ATA Controller 0 and Serial-ATA Controller 1
Sets the Serial ATA controller to Enhanced or Compatible.
Not Present
Not Present
Not Present
Not Present
[IDE Mode]
[Compatible]
[Enhanced]
→ ←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save ESC: Exit
