DR
®
TRIMMER/MOWER
™
Assembly & Operating Instructions 39
Parts List
Ref # Part # Description
1 116891 Main Frame
2 125121 Bearing Housing Assembly
3 117771 Upper Handlebar
4 117741 Lower Handlebar Ext.
5 125141 Wheel Retaining Ring
6 121171 Mow-Ball ™ Support
7 121131 Aluminum Mow-Ball ™
8 114261 Axle
9 123951 Clevis, 3/16" x 1/2"
10 114031 Brake Actuator
11 114111 Idler Arm
12 115121 Brake Assembly
13 136651 Clutch/Brake Control
14 115751 Throttle Handle Control
15 114681 Hex Head Bolt, 1/4"-20 x 1-1/4"
16 118181 Handlebar Knob
18 121761 Wire Spoke Wheel 16"
19 121321 Resin Wheel 16"
20 114301 Brake Bar
21 119621 Brake Rod
22 119011 Trimmer Head Plate
23 116801 Rubber Stone Guard
24 115641 Stone Guard Clamp
25 120891 Idler Return Spring
26 118221 PTA Lever
27 116201 5" Cutting Height Adjustment Disk
28 120521 Shield Assembly
29 121541 Bearing Shield Washer
30 121101 Pivot Stud
31 114611 Handlebar Bolt, 1/4"-20 x 1-1/2"
32 120641 Spacer, 1/4" x 1-3/4"
33 117491 PTA Lever Vinyl Grip
34 114251 PTA Latch Bracket Assembly
35 115001 Latch Bracket Only
36 118941 PTA Pin
37 120901 PTA Spring
38 119591 PTA Snap Ring
39 121751 Wear Strip
40 115831 24 Heavy-Duty Cords (pre-cut)
41 115871 Roll of Heavy-Duty Cord
42 115811 24 Extra Heavy-Duty Cords (pre-cut)
43 115861 Roll of Extra Heavy-Duty Cord
44 121661 Nylon Washer .20 thick
45 120771 Extension Spring
46 121521 Plastic Axle Washer
47 118161 Key 3/16" Square
48 121691 Flat Washer, 5/16"
49 114651 Mow Ball Bolt, 3/8"-16 x 3" HH
50 119191 Engine Pulley
Ref # Part # Description
51 120171 Set Screw, 5/16"-18 x 5/16"
52 125381 Head Pulley
53 118691 Hex Nut, 5/16"
54 118731 Nylon Lock Nut 10-24
55 114621 Hex Head Bolt, 1/4"-20 x 2-1/2"
56 121701 Flat Washer (3/8" SAE)
57 112391 Flat Washer (3/8" USS)
58 120161 Set Screw 1/4"-20 x 3/8" Sq Head
59 121551 Brake Pivot Washer
60 114431 V-Belt 1/2" x 45", 4L450
61 114781 Hex Head Screw, 10-24 x 5/8"
62 118641 1/4"-20 Elastic Stop Nut
64 121591 #10 Flat Washer
65 118781 Elastic Stop Nut, 3/8"-16
66 110761 Elastic Stop Nut Axle 5/16"-18
67 114741 Hex Head Bolt, 5/16" – 18 x 2"
68 114761 Hex Head Bolt (M50ES) 5/16-18 x 3-1/4"
69 114721 Hex Head Bolt, 3/8"-24 x 1/2"
70 119851 Hex Head Bolt, 3/8"-16 x 1-1/2"
71 119911 Shoulder screw
72 113071 Idler Pulley #1 (flat)
73 119101 Vinyl Plug
74 119381 Belt Retainer
75 119231 Idler Pulley #2 (V shape)
76 121681 Mow-Ball ™ Rectangular Washer
77 114851 Handlebar U-Bolt
78 117471 Safety Goggles
79 113081 Electric Starter Switch
80 114861 U Bolt, 1/4"-20 x 3/4"
81 121191 Switch Mounting Plate
82 117811 Ignition Wiring Harness
83 135101 Battery Clamp, Nylon
84 113001 Battery
85 113051 Neoprene Battery Mounting Pad
86 115071 Wagner Anti-Wrap Device Bracket
87 119611 Plastic Rivet
88 120151 Round Head Screw, 10-24 x 2"
89 127421 Cable Clip
90 118111 Key, Start Switch
91 118881 Brake Pad
92 133071 Flange Bolt, 1/4" – 20 x 7/8"
93 114411 Wheel Bearing
94 115581 Bowden Clamp, Briggs & Stratton Models
115591 Bowden Clamp, Tecumseh Models
95 119821 Bowden Clamp Bolt, Briggs & Stratton Models
115601 Bowden Clamp Bolt, Tecumseh Models
96 120101 Screw, Wear Strip
97 114381 Bearing
98 120481 Shaft
